02 3074 01 slewing bearing
Bearing Designations : 02 3074 01 slewing bearing
We are a professional manufacturer of slewing bearing 02 3074 01 rather than sales company of slewing bearing 02 3074 01. We not only provide high-quality products, but also provide customers with the most extensive pre-sales and after-sales services, as well as professional technical support.
Contructure Type: Four-contact Ball
Gear Type: Internal Gear
Closure Type: Double Seal
Inner Diameter : 217 mm
Outer Diameter : 385 mm
Total Height : 55 mm
Weight : 24 kg
02 3074 01 SLEWING BEARING DRAWING
Technical Specification
| Bearing Designations | 02 3074 01 |
| Row No. | single row |
| Standard | yes |
| Weight | 24kg |
| Structure | ball |
| Bearing Material | 50Mn,42CrMo |
| Ball Material | GCr15 |
| Transport | yes |
| Package | wooden case |
| Service | yes |
| Application | – |
| Quality Control | ISO 9001 |
| HS Code | 8482800000 |
| Inner Diameter | 217mm |
| Outer Diameter | 385mm |
| Total Height | 55mm |
| Boundary Dimension | 217mm*385mm*55mm |
| Number of Tooth | 366 |
| Precision Class | p0 p6 p5 |
| Seals Type | yes |
| Seal Material | Nitrile.Rubber |
| Gear Options | Internal Gear |
| Shipping Ways | by air/ by sea/ by express |
| Country origin | China |
Related Products
| 07 2810 09 | 02 2618 00 |
| 02 2560 00 | 07 2400 00 |
| 02 2202 00 | 02 2022 00 |
| 07 1997 04 | 02 2040 00 |
| 07 1830 04 | 02 1805 02 |
02 3074 01 Applications
Antennas and Radar
Equipment
Aviation and Aerospace Units
Bogie Bearings for Vehicles
Areal Hydraulic Platforms
Communication Systems
Steelmill Equipment
Excavators
Tower Cranes
Harbour and Shipyard Cranes
Machine Tools
Offshore Technology
Packaging and Filling
Rail Vehicles
Ship Deck Cranes
Mechanical Engineering
Stackers and Reclaimers
Telescopes
Water Treatment Equipment
Tunnelling Machines
Mobile Cranes
